General

Brand

Ubiquiti Networks

Model

AFI-P-HD

Specification

Specification

Max TX Power: 26 dBm

Radios: 2

MIMO Chains: 6

Speed: 1,750 Mbps

SUPPORTED DATA RATES (MBPS)
802.11ac: 13 Mbps to 1300 Mbps (MCS0 - MCS9, VHT 20 / 40 / 80)
802.11n: 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20 / 40)
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

ESD/EMP Protection: ± 24kV Air / Contact

Buttons: Reset

Antennas: (1) Dual-Band Antenna, Tri-Polarity

Wi-Fi Standards: 802.11ac

Power Save: Supported

Wireless Security: WPA2-PSK AES/TKIP

Operating Temperature: 14 to 131 degree F (-10 to 55 degree C)

Operating Humidity: 5 to 95% Noncondensing

Certifications: FCC / CE / IC

Features

Features

Home WiFi Mesh Technology for Complete Home Coverage

Can Be Used with AmpliFi Home WiFi System or Any Third Party Router

Plug and Play High Density Mesh Point to Eliminate Dead Spots

DualBand 802.11ac WiFi and 3 X 3 MIMO

Easy Setup and Powerful Wi-Fi Management using the AmpliFi App
