Model

Brand

VANTEC

Series

NexStar SX

Model

VAN-NST-M2STS3-BK

Details

Color

Black

Size

M.2 (NGFF), B Key or B+M Key (will not support NVMe module)

Type

Enclosure

Internal Interface

1 x M.2 (NGFF, B-Key)

External Interface

Standard USB 3.0 Micro-B

Specifications

M.2 size: Length support 22x42mm, 22x60mm or 22x80mm
M.2 SSD Support: M.2 (NGFF), B Key or B+M Key (will not support NVMe module)
Internal Interface: 1 x M.2 (NGFF, B-Key)
External Interface: Standard USB 3.0 Micro-B
Computer Interface: USB Type A required
USB cable connector: USB 3.0 Micro-B and USB 3.0 Type A
USB cable length: 475mm / 18 inches

Compatibility

Operating Systems Supported

System with USB 3.0 port, Windows 7/8/8.1/10 OS, OS X 10.6 or newer, or Linux OS

Features

Features

Design for M.2 (NGFF, B-Key or B+M-key) SSD to USB 3.0 interface
Support multi-size M.2 (NGFF) card, 22x42mm, 22x60mm or 22x80mm
Support UASP for added performance
Support SATA specifications
Easy install, Small form factor and durable construction
Uses minimum Bus power for better power management
Plug and Play ready

Dimensions & Weight

Dimensions

109.22 mm x 40.64 mm x 10.16 mm

Weight

68.04 g

Package Contents

Package Contents

NexStar SX M.2 SSD to USB 3.0 Enclosure, Quick Installation Guide, M.2 mount, Screw, Screwdriver, USB 3.0 Micro-B to A cable

Additional Information

Date First Available

May 22, 2020
