Socket AM4
CPU (Max Support) RYZEN 9
Chipset AMD® X570 Chipset
DDR4 Memory Supports 1866/ 2133/ 2400/ 2666MHz
Memory Channel Dual
DIMM Slots 4
Max Memory (GB) 128
PCI-E x16 1
PCI-E x4 1
PCI-E x1 3
SATAIII 6
M.2 Slot 2
RAID 0/1/10
TPM (header) 1
LAN 1x Realtek® 8111H Gigabit LAN Controller
USB 3.2 ports (Front) 4(Gen1, Type A)
USB 3.2 ports (Rear) 4(Gen1, Type A), 1(Gen2, Type A), 1(Gen2, Type C)
USB 2.0 ports (Front) 4
USB 2.0 ports (Rear) 2
Serial ports(Front) 1
Audio ports (Rear) 5+ Optical S/PDIF (Realtek® ALC1220 Codec)
HDMI 1
DirectX 12
Form Factor ATX
CrossFire Y
Operating System Support for Windows® 10 64-bit
