Cisco Isr 1100 8 Ports Dual Ge Wan Ethernet Router Poe+ Sfp+ Software Licenses And Performance Options
QUICK OVERVIEW
| Business need | Features/description |
| Lightweight, compact size with low power consumption | ● Can be deployed in many different environments where space, heat dissipation, and low power consumption are critical factors (Including Cisco Pluggable smaller form factor technology). |
| High performance to run concurrent services | ● High performance allows customers to take advantage of broadband network speeds while running secure, concurrent data, voice, video, and wireless services. |
| High availability and business continuity | ● Redundant WAN connections for failover protection and load balancing. ● Dynamic failover protocols such as Virtual Router Redundancy Protocol (VRRP; RFC 2338), Hot Standby Router Protocol (HSRP), and Multigroup HSRP (MHSRP). |
| Consistent, high application performance levels | ● The router can run multiple services simultaneously with minimal performance degradation. |
| Risk mitigation with multilevel security | ● Network perimeter security with integrated application inspection firewall. ● Data privacy through high-speed IP Security (IPsec) Triple Data Encryption Standard (3DES), and Advanced Encryption Standard (AES) encryption. ● High-performance VPNs: DMVPN, FlexVPN, GETVPN. ● Encrypted Traffic Analytics (ETA) to identify malware communications in encrypted traffic using passive monitoring, extraction of relevant data elements, and supervised machine learning with cloud-based global visibility. ● Cisco Umbrella™ is a cloud security platform that provides the first line of defense against threats on the internet wherever users go. ● Security hardware acceleration. ● Trustworthy systems with Field-Programmable Gate Array (FPGA) and hardware anchor. |
| Unified control of wired and wireless networks from a common console for streamlined operations | ● Simplifies and centralizes configuration and management of wireless and wireline devices. Supports WLAN services without requiring a wireless LAN controller. ● Supports Mobility Express for WLAN-enabled routers. |
| Remote configuration and management to keep local IT staff lean | ● Supports separate console/auxiliary and USB ports. Can be configured to work with optional USB token. ● Supports TR-069. |
| Performance ● Throughput ● Service reliability | ● ISR 1100 can provide encrypted traffic performance greater than 350 Mbps. ● A distributed multicore architecture with the dedicated control plane and service plane. ● Remote installation of application-aware services that run identically to their counterparts in dedicated appliances (Future roadmap). |
| Lower WAN expenditures | ● Cisco Software-Defined WAN (SD-WAN) support for optimized WAN connection. ● Smaller form factor and Cisco Pluggable technology provide additional protection investment and flexibility. |
| Pay as you grow: IPsec performance upgrade model | ● Router IPsec capacity can be increased with a remote performance-on-demand license upgrade (no hardware upgrade) for exceptional savings and CapEx budget management. |
| IT consolidation, space savings, and improved Total Cost of Ownership (TCO) | ● Single converged branch platform integrates routing, switching, security, and performance management capabilities. |
| Business continuity and increased resiliency | ● The entire 1100 Series supports Power over Ethernet (PoE) and PoE+ power to endpoints (Not available on C1101 smaller form factor series). |
| Model | C1111-8P |
| GE | 1 |
| GE/SFP combo | 1 |
| ADSL2/VDSL2+ | N/A |
| LTE Advanced (CAT6) | N/A |
| 802.11ac | N/A |
| GE | 8 |
| PoE | 4 |
| PoE+ | 2 |
| Integrated USB 3.0 AUX/console | Yes |
| Dimensions (H x W x D) | 1.75 x 12.7 x 9.03 in. (42 x 323 x 230mm) (includes rubber feet) |
| Weight with AC PS (w/o modules) | 5.5 Lbs. (2.5 kg) maximum |
Product Details
Figure 2 shows the back ports of C1111-8P. It doesn’t include the antennas.
Note:
| ① | LAN | ⑦ | GE 0/0/0 - SFP |
| ② | CLEI Label | ⑧ | GE 0/0/0 - RJ45 |
| ③ | Serial Number | ⑨ | GE 0/0/1 |
| ④ | Kensington Lock Slot | ⑩ | 4-pin Power Connector |
| ⑤ | RJ45 / Micro USB Console | ⑪ | Power Switch |
| ⑥ | USB3.0 | ⑫ | Reset Button |
