Cisco Webex Board 55S (CS-BOARD55S-G-K9)

SKU
295118
Brand
MPN
CS-BOARD55S-G-K9
Warranty
1 Year Manufacturer's return to base
Availability
In stock
Freight Estimate
Special Price $19,840.00 Regular Price $20,043.00
Buy Now And Earn 19840 Reward Points!

Cisco Webex Board product overview

The Cisco Webex Board revolutionizes the way we work by combining key requirements for team collaboration in the physical meeting room into a single device and connects it to the cloud for continuous workflow. It’s a wireless presentation screen, a digital whiteboard, and an audio and video conferencing system, all in one. The Webex Board helps teams collaborate in physical meeting rooms, but also securely connects to virtual meeting spaces to facilitate continuous workflow before, during, and after everyone has left the physical conference room. The Cisco Webex Board draws its power from the Cisco Webex service, which combines meeting, messaging, calling, and new white boarding capabilities on any Webex Teams or Webex Meetings app-enabled device. Registration to the Cisco Webex in the cloud lets you store everything created on the Webex Board directly in the cloud and associate it to a virtual Webex Teams space, so you can take your work wherever you go. The Webex Board solution offers an integrated, secure, and comprehensive lifecycle approach to teamwork that is as yet unimagined, and thus unmatched, by any other solution on the market.

The Cisco Webex Board 55S* is a fully self-contained system on a high-resolution 4K 55-inch LED screen. With an integrated 4K camera, embedded microphones, and a capacitive touch interface, the board brings intelligence, style, and usability to meeting rooms, from small to large. Designed with minimal wires for simplicity and elegance, Cisco’s latest collaboration device allows wireless sharing and Wi-Fi connectivity. The system is also touch-based for easy and rich team collaboration. Not only is the Webex Board beautiful to behold and effortless to use, it is also affordable to acquire and easy to install and deploy, so that it can be a fixture in all of your conference rooms.

New Page 1

Software

For cloud deployments - Cisco Webex Room OS, provisioned and updated by Cisco Webex

For on-premises deployments – CE9.8 or later

Components

Fully integrated unit is delivered with:

●  Multi-touch 55-inch LED display
●  4K camera
●  12-microphone array
●  Speakers
●  White boarding pen

Display

●  Edge LED LCD – 55-inch 4K, 350 nits, 16:9
●  Viewing angle: +- 89 degrees (all directions)
●  Number of colors: 1.07 billion (10 bit)
●  Contrast: 1:4000
●  Response time: 5.5 ms

User interface

●  Control the Webex Board from the touch screen
●  Capacitive touch screen with protective glass and optical bonding
●  Multi-touch
●  Optionally use Cisco Touch 10 control unit

Inputs and outputs

●  HDMI input
●  Home button
●  3.5-mm mini jack audio out (line out)
●  USB-C (future use)
●  USB micro (service)

Camera overview

●  Fixed lens, infinite focus
●  F-value: 2.8
●  4Kp60
●  Horizontal Field Of View (HFOV): 83 degrees
●  Vertical Field Of View (VFOV): 55 degrees
●  Camera mounted tilted: -25 degrees

Audio system

●  12-element microphone array (with intelligent voice tracking)
●  Integrated voice-optimized speakers

Network

●  Ethernet (RJ-45) 100/1000 Mbps
●  Wi-Fi 802.11a/b/g/n; 802.11ac (2.4 and 5 GHz)
●  Bluetooth ready
●  IPv4 Dynamic Host Configuration Protocol (DHCP)/static
●  IPv6 (both static and stateless address auto-configuration)
●  Network Time Protocol (NTP)
●  HTTP Proxy support (for signaling, not media)
●  Inspecting TLS Proxy supported
●  Cisco Discovery Protocol (CDP)
●  802.1X network authentication (Passphrase or X.509 client certificate)
●  802.1Q virtual LAN
●  802.1p (Qos and Class of Service [CoS])

User controls

●  Control Cisco Webex Board directly from the touchscreen or using the Cisco Webex Teams or Meetings app
●  Optionally use Cisco Touch 10 control unit

Language support

●  English, Spanish, German, French, French Canadian, Portuguese, Japanese, Czech, Danish, Dutch, Norwegian, Swedish, Latin American Spanish, Italian, Finnish, Polish, Turkish
●  Additional languages to be supported in future software release

System management

●  For cloud deployments - Cisco Webex Board is managed in the administrator Webex Control Hub, giving system status and overview, activation, configuration, metrics, and troubleshooting
//
