2 x Socket P (LGA 3647)
1st and 2nd Gen Xeon® Scalable Processor Family (165W)
*Refer to support page for more information
UPI (10.4 GT/s)

Intel® Lewisburg PCH C621

Total Slots : 8 (4-channel per CPU, 4 DIMM per CPU)
Capacity : Maximum up to 256GB RDIMM/Maximum up to 512GB LRDIMM/Maximum up to 1024GB LR-DIMM 3DS
Memory Type :
2933/2666/2400
Memory Size :
32GB, 16GB, 8GB, 4GB RDIMM
64GB, 32GB LRDIMM
128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.

Total Slot : 3
Slot Location 1 : PCI-E x8
Slot Location 3 : PCI-E x16
Slot Location 5 : PCI-E x16
Slot Location 6 : MIO Slot for Audio card

CEB (12"x10.5", 305mm x 267mm)

ASUS Fan Speed control technology
ASUS Control Center

SATA Controller :
Intel® C621
12 x SATA3 6Gb/s ports (12 by 3 Mini-SAS Connector)
Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
(Support Software RAID 0, 1, 5, 10 )
4 SATA3 6Gb/s port by 1miniSAS connector (Marvell 88SE9230)
Intel^®VROC (For Linux/Windows)
(Support Software RAID )
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card

4 x Intel® I210AT + 1 x Mgmt LAN

Aspeed AST2500 with 64MB VRAM

1 x TPM header
1 x PSU Power Connector (24-pin SSI power connector + 8-pin SSI 12V + 8-pin SSI 12V power connector)
1 x USB 3.0 pin header , Up to 2 Devices
1 x USB 2.0 pin header , Up to 2 Devices
8 x Fan Header , 4pin (3pin/4pin fan dual support)
1 x Serial Port Header
1 x SMBus
1 x Chassis Intruder
4 x Front LAN LED
2 x M.2 Connector , NGFF Type : 22110/2280/2260/2242
1 x VROC Key Header
1 x Q-Code/Port 80 LED

4 x USB 3.0 ports
1 x VGA port
4 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port

Rear Switch/LED:
1 x Power switch
1 x Message LED
1 x HDD LED
1 x Location LED
1 x BMC LED
1 x P5V LED

ACC(ASUS Control Center)
Onboard ASMB9-iKVM for KVM-over-Internet

Operation temperature: 10°C ~ 35°C
Non operation temperature: -40°C ~ 70°C
Non operation humidity: 20% ~ 90% (Non condensing)

Gift Box (1-in-1)
Net Weight : 1.24 KG
Gross Weight : 2.32 KG

Bulk Pack (10-in-1)
Net Weight : 1.24 KG
Gross Weight : 16.26 KG

I/O Shield
1 x Supporting DVD
2 x LGA3647 carrier

CPU Temperature
Fan RPM
